Bigboy Technologies use industry leader Samsung DDR5 modules for RDIMM modules.
DDR5 was developed to meet the growing IT needs due to the growing amount of data. Increased speed, improved capacity and stronger security features are combined in DDR5 to improve overall system performance. Offering high power savings with Samsung memory technologies, DDR5 provides environmentally friendly solutions.
Bigboy DDR5 RDIMM memory modules includes a register for enhancing clock, command and control signals.
Error correction available by adding 8 bit parity signals.
Depending on the capacity Bigboy DDR5 RDIMM modules support x4 / x8 Organization and 3DPC configuration
Specifications
- Capacity : 16GB, 32GB, 64GB, 96GB, 128GB, 256GB
- Speed : DDR5-4800, PC5-38400
- Latency : CL=40, tRCD=40, tRP=40
- Organization : (2G x 8) x 10 (16GB), (2G x 8) x 20 (32GB), (4G x 4) x 40 (64GB – 96GB), (2H 3DS 8G x 4) x 40 (128GB), (4H 3DS 16G x 4) x 40 (256GB),
- Rank : 16GB – Single Rank 1R x 8, 32GB – Dual Rank 2Rx8, 64GB – Dual Rank 2Rx4, 96GB – Dual Rank 2Rx4, 128GB – Quad Rank 4Rx4, 256GB – Octa Rank 8Rx4
- Number of Pin : 288
- Voltage : 1,1V
- Warranty : Limited Lifetime
- Part Number : BTS548-16G Datasheet, BTS548-32G Datasheet, BTS548-64G Datasheet, BTS548-96G Datasheet, BTS548-128G Datasheet, BTS548-256G Datasheet
